Skynnyn Lynnyrd Backline

Qty Discription
1 Condnser Microphones – Drum Overhead – Cymbals
1 Condenser Microphone – Hi-Hat
1 Kick Drum Microphone - AKG D112
1 Snare Drum Microphone
3 Tom-Tom Microphones
3 Instrument Microphones – Guitars – Shure M-57 or Equivalent
5 Vocal Microphones – Shure M-58 or Equivalent
2 Direct Input (DIs) – Keyboards - Unbalanced TRS to Balanced XLR
19 Mixer Channels - 21 Minimum with 4 Aux sends; 24 preferred
4 Wedge Monitors – 4 - Stage left, center, right + 1 Drums
2 Reverse X (Side) Fills – Large Stage - L mix of Rt, Rt mix of L
Active crossover Mains required. Consumer grade systems are not acceptable.

31 Band Equalization is required for indoor venue Mains.
Power requirements are dependent upon size of venue.

No FOH effects required.

Pro Sound System available upon reqest.
Inputs 25 Channel / 12 AUX

 CHANNEL#   SOURCE  NOTES
  1.  VOCAL STAR   +COMP
  2.  VOCAL BKGD
  3.  VOCAL BKGD
  4.  VOCAL BKGD
  5.  VOCAL BASS  FOH LEFT
  6.  GUITAR  FOH LEFT
  7.  GUITAR  FOH CENTER
  8.  GUITAR  FOH RIGHT
  9.  BASS GUITAR  ACCENTED HIGH  REGISTERS
 (tight) + COMP
 10.  SPARE
 11.  KICK  +75 Hz + 2.5 KHz +COMP
 12.  SNARE
 13.  TOM 1
 14.  TOM 2
 15.  TOM 3
 16.  TOM 4
 17.  TOM 5
 18.  HiHAT   -> 150 Hz
 19.  OVERHEAD  -> 150 Hz
 20.  PIANO
 21.  LESLIE LOW  -> 150 Hz
 22.  LESLIE HIGH
 23.  SYNTH
 24.  CD IN LEFT
 25.  CD IN RIGHT

 AUX 1  WEDGE FOH  LEFT
 AUX 2  WEDGE FOH  L.CTR
 AUX 3  WEDGE FOH  RIGHT
 AUX 4  WEDGE DRUMS
 AUX 5  SUB - DRUMS
 AUX 6  SPARE
 AUX 7  SPARE
 AUX 8  SUB  FOH
 AUX 9  VOCAL - STAR  IEM
 AUX 10  VOCALS (3)  BkUp  2 WEDGE MONITORS
 AUX 11  EFFECT  REVERB
 AUX 12  EFFECT  CHORUS or other
